SKYZONE TX2501 CNC 5.8G 2.5W 56CH L.X Band VTX
The TX2501 is powerful VTX which have 2.5W output, the new CNC case and fan can dispath the heat quickly , LED segment make the VTX easy to set and check the BAND/CH/POWER, its also support X Band(5G Hz) and Low Band.
Features:
1, Support X Band(5G Hz) and Low Band
2,CNC Case dan Fan to dispatch heat
3, 25/800/1600/2500mW adjustable power output
4, 7-26V Wide Range Voltage input
5, LED Segment Display, easy to check status of the VTX
6, Button/IRC control, fast to change the CH and Power
7, Allow use customized frequency 1Mhz by 1 Mhz from 4990~5945
8.MMCX Antenna connector, change the CH and Power with Button/IRC control
Notice: You can only choose one of the Button mode and the IRC mode. If you use the button mode, you need to turn off the IRC protocol in BF. The LED segment displays the BAND/CH and power in sequence in the button mode, and the frequency and power at IRC mode.
Purchase Instructions
The analog VTX is a wireless video signal transmission device, which is solely intended for civilian entertainment purposes.
1.When operating this product, ensure the working environment has adequate air circulation to prevent equipment damage caused by excessive temperature.
2.Prior to use, make sure the unit is securely installed, all wiring connections are intact, and all associated devices function properly to avoid accidents.
3.Do not operate this product in violation of relevant regulations issued by local governments or other administrative authorities, so as to prevent unnecessary losses.
4.The analog VTX is applicable for wireless video signal transmission of RC cars, boats, monitoring equipment and other similar devices.
Original: $4.99
-65%$4.99
$1.75
Description
The TX2501 is powerful VTX which have 2.5W output, the new CNC case and fan can dispath the heat quickly , LED segment make the VTX easy to set and check the BAND/CH/POWER, its also support X Band(5G Hz) and Low Band.
Features:
1, Support X Band(5G Hz) and Low Band
2,CNC Case dan Fan to dispatch heat
3, 25/800/1600/2500mW adjustable power output
4, 7-26V Wide Range Voltage input
5, LED Segment Display, easy to check status of the VTX
6, Button/IRC control, fast to change the CH and Power
7, Allow use customized frequency 1Mhz by 1 Mhz from 4990~5945
8.MMCX Antenna connector, change the CH and Power with Button/IRC control
Notice: You can only choose one of the Button mode and the IRC mode. If you use the button mode, you need to turn off the IRC protocol in BF. The LED segment displays the BAND/CH and power in sequence in the button mode, and the frequency and power at IRC mode.
Purchase Instructions
The analog VTX is a wireless video signal transmission device, which is solely intended for civilian entertainment purposes.
1.When operating this product, ensure the working environment has adequate air circulation to prevent equipment damage caused by excessive temperature.
2.Prior to use, make sure the unit is securely installed, all wiring connections are intact, and all associated devices function properly to avoid accidents.
3.Do not operate this product in violation of relevant regulations issued by local governments or other administrative authorities, so as to prevent unnecessary losses.
4.The analog VTX is applicable for wireless video signal transmission of RC cars, boats, monitoring equipment and other similar devices.
