BN-220 GPS Module

This module is a small, accurate, and powerful GPS module for FPV drones. It is easy to use and integrates well with a variety of drones and control systems.

Chip characteristics	Chip	M10050
Physicalparameters	Measure	22*20*6mm
	Weight	5g
	Working current	50ma/5.0V
	Working voltage	Direct current 3.6V-5.5V
Positioning mode	GPS+BDS+GALILEQ+SBAS+QZSS
Pilot lamp	TX light	The blue light flashes when the power is on, indicating that there is data output
	PPS light	The light is not on if it is not located; after 3D positioning, it begins to flash.
Support agreement	NMEA Ubox
